ESC Made by HobbyWing
Motor made by tws model
Factory wired
Packing without header
ESC spec (WP-1060 RTR)
Input votage : Lipo 2S or 3S Battery
Input power wire length : 11cm
Output power wire length : 20cm
Connector wire connector length : 18cm
BEC Output : 3A / 6V (switch mode)
Motor spec (tws 5S-13T 540 motor)
Motor Type : 540 Size, Brushed
Turns : 13T
Rotor : 5-Slot
Dimensions : 54.5mm X Ø36mm
Weight : 160g
Motor Shaft : Ø3.16mm
Cells : 2-3S LiPo / 6-9 Cell NiMH
KV Rating : 2250KV (16650RPM@2S / 25000RPM@3S)
__________________________________________________
NOTICE : Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.
